Built for Reliable Performance & Custom Integration
The SINDA H0136 36-Inch Range Hood Insert delivers reliable 600 CFM ventilation in a streamlined 304 stainless steel design. Built for custom cabinetry and hood enclosures, its four-speed single motor efficiently captures heat, smoke, and grease while dishwasher-safe baffle filters and dimmable LED lighting add everyday convenience.
Core Engineering & Performance
- Durable SUS304 stainless steel with a fingerprint-resistant surface.
- The three-minute delayed power-off function ensures that the process of smoke, grease, and odor absorption will not be interrupted.
- Adjustable energy-efficient 3W LED light illuminates the cooking area.
- Choose the appropriate airflow needed with four different settings.
- Easy-to-clean and dishwasher-safe baffle filters trap grease effectively Perfect fit in a custom hood or surrounding cabinetry.
- Perfect for customizing the fit in a custom hood or custom cabinetry.
- ETL Listed; Conform to the UL 507; Certified to CSA Std.C22.2 No.113.
Performance & Design Highlights
Clear The Kitchen Air
|
Dishwasher-SafeCommercial-grade stainless steel baffle filters capture grease efficiently and are fully dishwasher-safe for low-maintenance upkeep.
|
Low Noise
|
Adjustable LED LightsDual LED dimmable lighting lets you choose the appropriate light for your cooking situation. |
General
| Installation Type | Built-in |
| Air Circulation | Ducted |
| Type of Control | Electronic Control Panel (Push Button) |
Features
| Body Design | Seamless Stainless Steel, Satin Finish |
| Custom Insert | √ |
| Removable Grease Filter(s) | √ |
| Grease Filter Material | Dishwasher-safe Stainless Steel |
| Fan Speed Control | 4-Speed |
Details
| Power Rating | 120V / 60HZ |
| Round Duct | 6” |
| Weight | 55.06 lbs |
| ELT Listed | ETL Listed (UL 507 & CSA C22.2 No. 113 Certified) |
| Grease Filter Material | Washable Stainless Steel |
| Airflow | 200CFM 360CFM 530CFM 600CFM |
| Noise Level | 1.2Sone (43dB) 2.8Sone (55dB) 5.0Sone (63dB) 7.0Sone (68dB) |
| Wattage | 120W (Delayed Power Auto Shut Off) |
| Motor | Single |
Warranty
| Hood Liner / Insert | 2-Year Limited Warranty |
| Motor / Blower | 10-Year Limited Warranty |
Download Spec Sheet
